Vento CM Fix

A little more grit.

Vento CM Fix

A little more grit.

Agile and dynamic

VENTO CM FIX will seduce you with its traditional elegance: VENTO CM FIX for urban tracks has an extra gear thanks to the powerful CM FIVE central motor integrated into the frame that allows you to overcome overpasses and challenging slopes. The Shimano 7-speed gearbox and the comfortable saddle of Selle Bassano complete the profile.

Download Brochure
User Manuals

Available colors

vento cm fix ebike

Technical service

Discover the support and after-sales services provided by our network of dealers.

Store locator

If you want to see and try out electric bicycles Wayel, find the dealer nearest you.

Technical features

Transmission

Chain KMC

Battery

FIVE – Samsung cells

Medium Battery

313 Wh | 36 V - 8,7 Ah | 2,1 kg | 5h

Long Battery

417 Wh | 36 V - 11,6 Ah | 2,25 kg | 6h

Extralong Battery

504 Wh | 36 V - 14 Ah | 2,25 kg | 6,5h

Max autonomy - Medium

90 km

Max autonomy - Long

120 km

Max autonomy - Extralong

140 km

Frame

Aluminium

Wheels

26'' x 1,75''

Motor torque

Central FIVE CM 250W 60Nm brushless

Brakes

Front and rear V brake

Weight (no battery)

20,5 kg

Front fork

Fixed

Gear

7-speed Shimano

Pedalling sensor

Integrated speed sensor

Saddle

Selle Bassano

Lights

Front and rear battery - LED

Display

Multifunction control unit with backlight LCD: 5 levels of engine assist and soft start device

Highlights

Central motor CM FIVE

250W brushless FIVE central motor, combined with the 7-speed Shimano gearbox, ensures a decisive push for the most demanding slopes.

7-speed Shimano gearbox

To perfectly adapt the chosen speed to the slope of the road and your physical condition, allowing you to reduce stress or increase the pedal resistance in relation to your travel needs.

LCD Display

LCD display with backlight, which allows to turn the system on and off, to select the assistance levels, to activate the soft start and to check the battery level.
